Illuminator 6 Knights Series

The Illuminator 4 & 6 offers versatile light output by featuring rotating adjustable height setting, allowing various beam spreads. The frosted cylindrical lens minimizes glare while the FLEX GOLD™ Series T3 LED lamp provides sufficient light to cast soft glows on any path or walking area. Ideal for walkways, the Illuminator 6is also perfect for when planter areas need lighting.

Equipped with a FLEX GOLD™ Series T3 LED lamp, a designer lens and 25’ of #18/2 low voltage wire, the Illuminator 6 carries a 15 Year Warranty.

Why Knights

Mobile Apps

Where to Buy

Specifications

Materials	Crafted from extruded copper.
Stem	Copper unibody design provides enclosed water resistant wire way. Integrated bung for maximum mechanical strength. High temperature, double o-ring retention collar provides a weather-tight seal.
Collar	Machined brass with double o-ring retention seal.
Shroud	Fully machined. Reflective Powder Coat Interior.
Lens	Shock resistant, frosted Borosilicate Glass lens. The lens is threaded and replaceable.
Lamp	For use with FLEX GOLD™ Series T3 LED lamps, available in 1W and 2W, 3000K color temperature. Also compatible with up to 20-watt Astro-Brite lamp.
Electrical Requirement	A remote 12V transformer is required and may be ordered separately from Unique Lighting Systems®. Voltage range for 12V halogen lamps is 10.8V to 12V. Voltage range for 12V FLEX GOLD™ Series LED lamps is 10V-15V.
Socket	Specification grade, beryllium copper lamp holder. GU5.3 base.
Wiring	Exclusive UF Intelli-Flex wire with anti-moisture migration connections.
Mounting Hardware	The standard mounting stake is injection molded PVC with a ½” NPS threaded female fitting.
